Double collet holder with Mini nut

120.02.D.10

EAN-kod: 4250001108397

ER16 - 1/10 - 70, Ø = 20

VAT 0% 96,00 €

Kontrollerar lagersaldo

In stock, shipping time UPS Standard 1 week

You need to log in before purchasing. Request credentials here.

Ask about this product

Application:
For mounting straight-shank tools in collets.

Delivery:
With balanced clamping nut

Description Symbol Value

Type

426E, ER 16

Mounting Ø, machine side

DCONMS

20 mm

Shank length

LS

70 mm

Adaptive interface machine direction

ADINTMS

Cylindrical shank

Adaptive interface workpiece direction

ADINTWS

ISO 15488 (DIN 6499) ER

Body diameter 2

BD2

123

Clamping Ø, nominal, workpc. side

DCONWS

1 - 10

Diameter lock nut

DLN

22

Drive size

DRVS

17

Thread designation inside

THID

-

Coolant entry diameter

CND

10
